HARDWARE HIGHLIGHTS

• • 24 x 1G SFP ports
•  4 x 10G SFP+ Uplink ports
• 1 x RJ45 Console port
• • 1 x Mini USB Console port
• • 1 x USB 2.0 Storage port
• • Switching Capacity: 128 Gbps
• • Thunder Protection: ±6 KV
• • Power: 100W
•  2 Temperature Control Fans
• • Power Supply: Dual 1+1 Power Supplies (AC + DC)
• • AC: 100~240V 50/60Hz, DC: 12V, 8.3A
• • SoldierOS L3 IP Base Software Feature Set
• • L3+ 10G SFP+ Uplink Fiber Routing Switch
• • 5 Year Extendable Warrant

L3 FEATURES

•  Static Route
• • Dynamic Routing, RIPv1/v2, OSPF v1/v2
• Policy-based Routing (PBR) for IPv4 and IPv6
• • VRRP
• • IGMP v1/v2/v3, IGMP Proxy
• • Static Multicast Route
• • Multicast Receive Control
• • Illegal Multicast Source Detect
• • ARP Guard, Local ARP proxy, Proxy ARP, ARP Binding, Gratuitous ARP, ARP Limit
• • Dynamic ARP Inspection (DAI)
• • DNS Server, Client, DNS Relay
